7130LS Series Layer 1+ FPGA Switch
The Arista 7130LS Series FPGA-enabled devices leverage FPGA technology to enable the development and deployment of cutting-edge network applications.
The Arista 7130LS Series FPGA-enabled devices leverage FPGA technology to enable the development and deployment of cutting-edge network applications. Available in 32, 48 or 96 SFP+ port options, the 7130LS Series combines multiple devices in one; performing layer 1+ switching in only 5 nanoseconds, enabling unrestricted access to an onboard FPGA and containing an x86_64 server. The 7130LS Series is optimized for Arista's FPGA-based network applications and can equally be leveraged to run 3rd party partner applications. FPGA application developers can utilize the platform to deploy and deliver their performance critical apps. On top of the market-leading FPGA functionality, the devices combine a range of Layer 1+ network functionality on to the same devices:
- Signal regeneration
- Port mirroring
- Dynamic patching/link management
- Ad-hoc tapping without rewiring
- Layer 1+ statistics on every link
- Media conversion
- Telemetry and more
Features and Benefits
The capabilities that set Arista 7130LS Series apart.
Performance
7130-48LS/LBS
7130-96LS/LBS
Advanced L1 Functionality
Signal Regeneration
Media Conversion
Talk to an Arista networking specialist
Get pre-sales help sizing and configuring Arista 7130LS Series for your network — from leaf/spine design to EOS and CloudVision integration.
Talk to a specialistTechnical Specifications
Hardware and software metrics extracted directly from the official Arista datasheet.
-
Ports48 x SFP+, 2 x RJ45
-
FPGAXilinx Virtex UltraScale+ FPGA
-
FPGA ModelVU7P Speed Grade 2
-
DRAM32GB DDR
-
SSD Drive BaysNo
-
External PCIENo
-
Internal 10G Ports2
-
Throughput100M-11.3Gbps
-
Layer 1 Latency5 ns
-
MetaMux Latency43 ns
-
Ports48 x SFP+, 2 x RJ45
-
FPGA ModelVU7P Speed Grade 2
-
DRAM32GB DDR
-
Internal 10G Ports2
-
Throughput100M-11.3Gbps
-
Layer 1 Latency5 ns
-
MetaMux Latency43 ns
-
MultiAccess Latency55 ns
-
MetaWatchYes
-
ExchangeAppYes
-
Ports96 x SFP+, 2 x RJ45
-
FPGA ModelVU7P Speed Grade 2
-
DRAM32GB DDR
-
Internal 10G Ports2
-
Throughput100M-11.3Gbps
-
Layer 1 Latency6 ns
-
MetaMux Latency43 ns
-
MultiAccess Latency55 ns
-
MetaWatchYes
-
ExchangeAppYes
-
Ports96 x SFP+, 2 x RJ45
-
FPGA ModelVU7P Speed Grade 2
-
DRAM32GB DDR
-
Internal 10G Ports2
-
Throughput100M-11.3Gbps
-
Layer 1 Latency6 ns
-
ClockAtomic
-
Rack Units2U
-
Max Power Draw388W
-
Weight12kg/26lbs
Compare Arista 7130LS Series Series
Select the right scale for your network workload.
| Model Name | Max Capacity | Port Config | Action |
|---|---|---|---|
| 7130-48LS E | 100M-11.3Gbps; 5 ns Layer 1 Latency | 48 x SFP+, 2 x RJ45 | Get Quote |
| 7130-48LAS E | 100M-11.3Gbps; 5 ns Layer 1 Latency | 48 x SFP+, 2 x RJ45 | Get Quote |
| 7130-96LS E | 100M-11.3Gbps; 6 ns Layer 1 Latency | 96 x SFP+, 2 x RJ45 | Get Quote |
| 7130-96LAS E | 100M-11.3Gbps; 6 ns Layer 1 Latency | 96 x SFP+, 2 x RJ45 | Get Quote |
| 7130-48LBS | 100M-11.3Gbps; 5 ns Layer 1 Latency | 48 x SFP+, 2 x RJ45 | Get Quote |
| 7130-48LBAS | 100M-11.3Gbps; 5 ns Layer 1 Latency | 48 x SFP+, 2 x RJ45 | Get Quote |
| 7130-96LBS | 100M-11.3Gbps; 6 ns Layer 1 Latency | 96 x SFP+, 2 x RJ45 | Get Quote |
| 7130-96LBAS | 100M-11.3Gbps; 6 ns Layer 1 Latency | 96 x SFP+, 2 x RJ45 | Get Quote |
